2-7
MAN0448_Issue 13_01-2010 5704 Control System
005704-M-5001 A03249
CHAPTER 2 - SYSTEM DESCRIPTION
Eight Card Cabinet Installation
Blanking Panel
8-Way AC to DC Power Supply Unit
Control Cards and Engineering Card
Interface/Relay Cards and DC Input Card
Accessory Plate suitable for mounting DIN rails,
circuit breakers, relays, etc.
16 Card Cabinet Installation
Blanking Panel
16-Way AC to DC
Power Supply Unit
Control Cards
and Engineering Card
Interface/Relay Cards
and DC input Card
Accessory Plate suitable
for mounting DIN rails,
circuit breakers, relays, etc.
