Honeywell 5704

4-11
CHAPTER 4 - INSTALLATION INSTRUCTIONS
MAN0448_Issue 13_01-2010 5704 Control System
005704-M-5001 A03249
Wall Mounting Bracket Hole Locations Cabinet Mounting Brackets
630
8 way 337
16 way 540
All dimension shown in mm.
268
Cabinet Dimensions:
9
10.2
36
9
27
15
10
100
15
100
430
8 way 367
16 way 57
15
All dimension shown in mm.
