Point Programming
SWITCH
(cont.)
FIRE TAMPER Latching Performs identically to a supervisory switch, but will be indicated as a tamper
switch on the LCD annunciator.
Non Latching
MANUAL
RELEASE
Manual release switch
INTERLOCK Interlock release switch input.
STATUS POINT
ECS INPUT Latching User also has ECS Event Number 1-8 option for ECS INPUT.
Only available when an ECS-VCM/ECS-NVCM is installed in the system.
Non Latching
ECS TAMPER Latching
Non Latching
ECS SUPER-
VISORY
Latching
Non Latching
CO DETECT
SWITCH
CO Detector Switch
CO
SUPERVISORY
DETECT SWITCH
Latching CO Supervisory Detector Switch
Non Latching
NOTIF OUTPUT PT Select Group Output point, a general use notification type. Use for driving standard notification
appliances.
AUX CONST Use constant power for applications that require a constant auxiliary power
source. Power is always present at constant circuits. See “Constant Power” on
page 55 for more information.
AUX RESET Use for auxiliary power, resettable applications. See “Resettable Power” on
page 55 for a description of how this option operates.
AUX DOOR Use for auxiliary power, door holder applications. For example, if you were using
an auxiliary power supply for door holders, you would use this option. See “Door
Holder Power” on page 55 for a description of how this option operates.
RELAY OUTPUT PT Select Group Output point, a general use relay type. Use for applications requiring a relay, such
as fan shutdown, elevator recall, and so on.
AUX RESET Use for auxiliary power, resettable applications. See Section “Resettable Power”
on page 55 for a description of how this option operates.
AUX DOOR Use for auxiliary power, door holder applications. For example, if you were using
an auxiliary power supply for door holders, you would use this option. See “Door
Holder Power” on page 55 for a description of how this option operates.
SLC LED LED NUMBER 01-80 For use with SD devices only. 80 sub addresses on LED.
LED FUNCTION Unused
NOTIF Notification can have group number.
Type
Selection
Function Latching Option Comments
Table 8.6 Programming Options for 5815XL Modules (Continued)
To Next Page
