IFP-300 Series Manual — P/N LS10145-001SK-E:C 4/6/2022 103
Point Programming
8.5.1 Point Programming for a 5815XL Module
To program for points on an 5815XL module, follow these steps:
1. Login to the panel. The panel will automatically access the Main Menu.
2. Select 7 for Panel Programming.
3. Press 4 to enter the Point Menu.
4. Press the up or down arrow key to select the desired module. Refer to Section 7.5 for available choices. Then, press ENTER.
5. Enter the number of the point you want to edit, then press ENTER.
6. Select the type of device by pressing the up or down arrow key. Refer to Table 8.6 under the column heading “Type Selection” for a list
of choices.
ECS-VCM,
ECS-NVCM,
ECS-RVM
UNUSED Refer to comments column of Table 8.7 on page 106 for description of
these options.
Latch or Non-latching feature only appears for WATERFLOW, FIRE
SUPERVISORY, FIRE TAMPER, ZONE AUX1, ZONE AUX2, SYSTEM
AUX1, SYSTEM AUX2, ECS INPUT, ECS TAMPER, and ECS
SUPERVISORY.
SWITCH MANUAL PULL
WATERFLOW
FIRE SUPERVISORY
FIRE TAMPER
FIRE DRILL
SILENCE
RESET
P.A.S. ACK
ZONE AUX1
ZONE AUX2
SYSTEM AUX1
SYSTEM AUX2
MANUAL RELEASE
INTERLOCK
STATUS POINT
VOICE AUX STATUS 1-2
VOICE AUX ECS 1-4
Background Music
ECS INPUT User also has ECS Event Number 1-8 option for ECS INPUT.
Only available when an ECS-VCM or ECS-NVCM is installed in the
system.
ECS TAMPER
ECS SUPERVISORY
Choices Type Selections
Function Selections for
each Type
Comments
Table 8.5 Point Programming Options
Type
Selection
Function Latching Option Comments
UNUSED Select for SLC points that are unused.
DETECTOR PHOTO Spot photoelectric detectors.
ION Spot ionization detector.
HEAT Spot heat detector.
PHOTO DUCT Duct photoelectric detector.
ION DUCT Duct Ion detector.
2-WIRE SMOKE 2-wire smoke detector.
SUP DET PHOTO Latching
Non Latching
Use this option when you want a detector to indicate a supervisory alarm.
ION
HEAT
PHOTO DUCT
ION DUCT
Table 8.6 Programming Options for 5815XL Modules
To Next Page
