Page #15 background imageLoading...
Page #15 background image
IFP-300 Series Manual — P/N LS10145-001SK-E:C 4/6/2022 15
Underwriters Laboratories (UL) Agency Listings, Approvals, and Requirements
Restricted Options
• The loss of AC signal is defaulted to 3-hours however the system allows settings from 0 - 3 hours. For UL certified installations, this
number must be set from 1 to 3 hours.
• The system allows the use of non-latching spot type smoke detectors. This feature may not be used in commercial applications whereby
a general alarm is sounded. It is intended for elevator recall, door holding applications, and hotel/motel room applications.
• The system allows the Alarm Verification time to be set from 60 to 250 seconds. For UL certified installations, the setting must be a
minimum of 60 seconds.
• The system allows the Auto-resound time to be set to 24 or 4 hours. For UL certified installations that are utilizing SWIFT devices, the
value must be set to 4 hours.
• Call forwarding shall not be used.
• When the two-count feature is used, detector spacing shall be cut in half, you shall not use the Alarm Verification feature, and no delay
shall be used.
• P.A.S (Positive Alarm Sequence) feature shall be used only with automatic detectors.
2.2.2 UL 864 9th and 10th Edition
• Per the UL Continuing Certification Program, UL 864 9th edition fire alarm control equipment will retain certification after the roll-out
of UL 10th edition (12/2/2018).
• Installations of UL 864 10th Edition certified equipment are permitted to use UL864 9th Edition certified equipment when approved by
the local Authority Having Jurisdiction (AHJ).
For product compliance, refer to the UL/ULC listing cards located on the UL online certification directory. https://iq.ulprospector.com
2.2.3 Requirements for Central Station Fire Alarm Systems
1. Use both phone lines. Enable phone line monitors for both lines.
2. You must program a phone number and a test time so that the IFP-300 shall automatically initiate and complete a test signal
transmission sequence to its associated receiver at least once every 6 hours, using two phones or one phone line with Ethernet/cellular
backup. The AC Loss Hours option must be set from 1-3 hours.
3. If using wired Ethernet or cellular, you must program the corresponding Account/Subscriber ID and a test time so that the FACP shall
automatically initiate a Test Signal Transmission sequence to its associated receiver at least once every 6 hours.
The Automatic 6 hour Test Signal Transmission only applies if the secondary communication paths are utilized. If no secondary
communication paths are utilized, the FACP shall automatically initiate a Test Signal Transmission sequence to associate the receiver at
least once every 60 minutes.
2.2.4 Requirements for Local Protected Fire Alarm Systems
At least one UL listed supervised notification appliance must be used.
2.2.5 Requirements for Remote Station Protected Fire Alarm Systems
Minimum system requirements are one Honeywell addressable initiating device and either a 5220, Keltron 3158 or the built-in Digital Alarm
Communicator Transmitter (DACT).
1. Do not exceed the current load restrictions shown in Section 3.5.5.
2. The AC Loss Hours option must be set from 1-3 hours.
2.2.6 Requirements for the Installation of Carbon Monoxide (CO) Detection and Warning
Equipment, NFPA 720
When using carbon monoxide detection the system must be monitored by a Supervising Station with emergency response, both aspects meet-
ing the Standard for the Installation of Carbon Monoxide (CO) Detection and Warning Equipment, NFPA 720.
2.2.7 NFPA Requirements
The following is the minimum configuration to meet the NFPA requirements.
Model/Module Description Local Releasing
Remote
Station
Auxiliary
Central
Station
Emergency
Signaling
IFP-300 Control Unit YYYYYY
6861BIA/6861GIA 4 x 40 display YYYYYY
5815XL SLC Expander OOOOOO
6815 SLC Expander OOOOOO
SK-NIC Network card OOOOOO
SK-FML/ -FSL Fiber module OOOOOO
7644-L8 Pol Rev device N N Y N N N
5220 City tie, Pol. Rev Device N N Y Y N N
Keltron 3158 Reverse Polarity Module N N Y Y N N
CELL-MOD/CELL-CAB-SK
Cellular transmitter N N Y
1
NY
1
N
HWF2A-COM/HWF2V-COM Fire Communicators N N Y
1
NY
1
N
Table 2.1 NFPA Requirements for IFP-300
