7.4 Programming Using an Annunciator
You can program the control panel from a system annunciator, using either the control panel’s onboard annunciator or an RA-100, RA-1000
or RA-2000 remote annunciator.
The following subsections describe programming basics, including a description of editing keys available for programming and how to move
through programming menus. Section 8 contains specific information about individual programming options.
7.4.1 Entering / Exiting Panel Programming
Entering Programming Mode
1. Login to the panel. (Refer to Section 9.2.1).
2. Select 7 for the Programming Menu. See Section 8 for detailed information and Section 7.5 for a quick reference listing all
programmable options and JumpStart defaults.
Exiting Programming Mode
When you have completed working with the menus, press the left arrow several times until you exit from the Programming Mode. Two
prompts will display. At the first prompt, a message appears indicating to exit the Program Menu (select Yes or No as appropriate). At the
second prompt, a message indicates if the user accepts all changes. If you select No, any changes you have made since you entered the Pro-
gram Menu will have no effect.
7.4.2 Moving through the Menus
Figure 7.9 shows how to move or navigate through program menu screens using the Main Menu screen as an example.
7.4.3 Selecting Options and Entering Data
There are several ways to make programming selections using the control panel depending on which screen you are currently using. The
chart below is a generic explanation.
NOTE: Output mapping cannot be programmed through the onboard and remote annunciators. Mapping is only available through the HFSS
Honeywell Fire Software Suite.
<Main Menu> Panel 2
2=Point Functions
3 Event History
4 Set Time & Date
Arrows on the LCD
indicate that there are
more options available
by pressing the up/down
arrow keys.
The option available for
editing displays on the
second row. An equal
sign (=) follows the
option number.
Press Enter to select
the desired option.
The first line of the display identifies the menu.
Press the up/down arrow keys
to move through the menus.
Figure 7.9 Moving through Program Menu
To Press
Select from a menu Enter the number of the option.
Enter numeric data Press the appropriate number on the annunciator.
Enter text (alphanumeric data)
Enter each character individually using the Up and Down arrow keys until the one you wish to select
displays. Then press right arrow to select the character. See Appendix A for a complete list of
characters.
Select from a scrolling list Use up arrow and down arrow to move through a list of available options. When the option you want
to select is displayed, press ENTER.
