Appendix C: Cadence Patterns
Table C.1 shows the cadence patterns available for use with the control panel.
# Name Pattern Description (Patterns repeat until condition is cleared.)
00 Constant Continuous sound (This is the only pattern that can be used for relay circuits. The system will
override any other choice.)
01 March Time 0.5 second on, 0.5 second off
02 ANSI 3.41 0.5 sec on, 0.5 sec off, 0.5 sec on, 0.5 sec off, 0.5 sec on, 1.5 sec off
03 Single Stroke 0.1 sec on, 1 sec off, 0.1 sec on, 1 sec off, 0.1 sec on, 3 sec off
04 California 5 sec on, 10 sec off
05 Zone-coded, Zone 1 0.5 sec on, 0.5 sec off
This pattern is multiplied by the zone number in alarm, followed by 3 seconds off.
For example, Pattern 6, Zone 2 coded: (pattern x two):
0.5 sec on, 0.5 sec off, 0.5 sec on, 0.5 sec off, 3 sec off
06 Zone-coded, Zone 2
07 Zone-coded, Zone 3
08 Zone-coded, Zone 4
09 Zone-coded, Zone 5
10 Zone-coded, Zone 6
11 Zone-coded, Zone 7
12 Zone-coded, Zone 8
13 Zone-coded, Custom 1
14 Zone-coded, Custom 2
15 Zone-coded, Custom 3
16 Zone-coded, Custom 4
17 Sync Type- Faraday (N/A) These outputs provide synchronization for Gentex, System Sensor, Wheelock, or AMESECO
synchronized appliances.
18 Sync Type- Gentex
19 Sync Type- System Sensor
20 Sync Type- Wheelock
21 Sync Type- AMSECO
22 Power Isolated Disconnected. No voltage at terminals.
23 Temporal 4 0.1 sec on, 0.1 sec off, 0.1 sec on, 0.1 sec off, 0.1 sec on, 0.1 sec off, 0.1 sec on, 5 sec off,
Table C.1 Cadence Patterns
