IFP-300 Series Manual — P/N LS10145-001SK-E:C 4/6/2022 95
Section 8: Programming
This section of the manual describes how to manually program the control panel from the built-in annunciator. Each subsection discusses
these menu options in detail. All options described in this section can be performed using the HFSS Honeywell Fire Software Suite.
8.1 UL 864 / UL 2572 Programming Requirements
8.2 Modules
This section lists the options available under the module option in the program menu. The following modules are available for the control
panel: RA-100, RA-1000 or RA-2000 LCD Annunciators, 5815XL SLC loop expander for SD devices, 6815 SLC Loop Expander for IDP or
SK devices, 5824 serial/parallel printer interface module, 5496 NAC Expander, RPS-1000 intelligent power module, 5880 LED I/O module,
5865 LED annunciator, ECS-50W, ECS-125W, ECS-INT50W, ECS-DUAL50W watt audio amplifier, ECS-VCM voice control module,
ECS-NVCM network voice control module, ECS-RVM remote voice module, and SK-NIC network interface card.
8.2.1 Edit Modules
The features that can be edited when this option is selected are, module name and class of wiring (Class A or Class B).
To edit an existing module, follow these steps:
1. Login to the panel.
NOTE: JumpStart auto-programming should be run Before any customized programming is performed. Thoroughly test the system after
running JumpStart because it automatically programs the system, searching for and configuring all SLC and SBUS devices it finds. JumpStart
allows you to confirm the integrity of the installation prior to performing any custom programming. After determining that the hardware is properly
installed, custom programming can be performed.
NOTICE TO USERS, INSTALLERS, AUTHORITIES HAVING JURISDICTION, AND OTHER INVOLVED PARTIES:
This product incorporates field programmable software. In order for the product to comply with the requirements in the Standard for
Control Units and Accessories for Fire Alarm Systems, UL 864 and UL 2572, certain programming features or options must be limited to
specific values or not used at all as indicated below.
Programming Option Menu Item
Permitted
in UL 864
(Y/N)
Permitted
in UL 2572
(Y/N)
Possible Settings
Settings Permitted
in UL 864
Settings Permitted in
UL 2572
Time Options Auto-resound Yes Yes 4 hrs, 24hrs 4 hours if using
SWIFT devices
24 hours if using
other devices
4 hours if using
SWIFT devices
24 hours if using other
devices
Time Options Low AC Report Delay Yes Yes 0-30 hours 1-3 hours 1-3 hours
Communication Options Auto Test Time Yes Yes 4, 6, 12, and 24 hrs 4 or 6 hours 4 or 6 hours
Silencing Options Auto Silence Yes Yes 0-60 minutes 3-60 minutes 3-60 minutes
Display Oldest Event Y (Enabled) Yes Yes Yes or No Yes Yes
N (Disabled) No No Yes or No No No
Initial Delay 0-28 Yes Yes 0-28 hours 3 hours 3 hours
Inter Message Delay 4-32 No No 4-32 hours 4-32 hours 4-28 hours
Alarm Verification
1
1 When 2-count delay is active, you cannot use the alarm verification.
Alarm Verification Yes Yes 60-250 seconds
(Confirmation
period)
0-60 seconds 0-60 seconds
Manual Release Switch
2
2 The Manual Release Switch shall override any pre-discharge delays resulting in an immediate release or start of the Manual Release Delay
period. The delay period shall be 30 seconds or less from the activation of the switch to the actuation of the releasing device(s).
Manual Release Yes Yes 0-120 seconds
(delay period)
0-30 seconds
(delay period)
0-30 seconds
(delay period)
Auto Reset
ECS MIC Triggered Event
Auto Reset ECS MIC
Triggered Event
Yes Yes Never
Timer Event
Disabled
Never
Timer Event
Disabled
Never
Timer Event
Disabled
ECS Input ECS Input Yes Yes Latching
Non-Latching
Latching Latching
Event Priority CO Alarm No No Yes & No No No
Table 8.1 Programming Requirements
NOTE: Use software version 7.0 or higher.
