106 IFP-300 Series Manual — P/N LS10145-001SK-E:C 4/6/2022
Programming Point
8.5.2 Point Programming for a 6815 Module
To program for points on a 6815 module, follow these steps:
1. Login to the panel. The panel will automatically access the Main Menu.
2. Select 7 for Panel Programming.
3. Press 4 to enter the Point Menu.
4. Press the up or down arrow key to select the desired module. Refer to Section 7.5 for available choices. Then, press ENTER.
5. Select S for sensor or M for module. (IDP or SK devices only)
6. Enter the number of the point you want to edit, then press ENTER.
7. Select the type of device by pressing the up or down arrow key. Refer to the column heading, "Type Selection" in the table below for a
list of choices.
Type
Selection
Function Latching Option Comments
UNUSED Select for SLC points that are unused.
DETECTOR PHOTO Spot photoelectric detectors.
ION Spot ionization detector.
HEAT Spot heat detector.
PHOTO DUCT Duct photoelectric detector.
ACCLIMATE Acclimate photoelectric detector.
HEAT HT High temperature heat detector.
PHOTO-HEAT Photoelectric detector with heat sensor.
BEAM Beam smoke detector.
2-WIRE SMOKE 2-wire smoke detector.
SUP DET PHOTO Latching
Non Latching
Use this option when you want a detector to indicate a supervisory alarm.
ION
HEAT
PHOTO DUCT
ACCLIMATE
HEAT HT
PHOTO-HEAT
BEAM
CO SMOKE
DETECTOR
CO ALRM /
FIRE ALRM
No Accessory Base, Sounder base, Relay Base, or Intelligent Sounder base.
Bases can be set for Single station or Multi station, Silence or Non-Silence, Latching or
non-latching. Intelligent sounder bases can have volume set for high or low.
CO ALRM /
FIRE SUPR
CO SUPR /
FIRE ALRM
CO SUPR /
FIRE SUPR
Latching
Non Latching
Supervisory switches can be latching or non-latching.
W-DETECTOR PHOTO Latching
Non Latching
Wireless photoelectric detectors
ACCLIMATE (IDP) Wireless acclimate photoelectric detector
HEAT Wireless heat detector
PHOTO-HEAT
(SK)
W-SUP DET Same as
W-Detector
Latching
Non Latching
Wireless photoelectric detectors
Table 8.7 Programming Options for 6815 Modules
