IFP-300 Series Manual — P/N LS10145-001SK-E:C 4/6/2022 121
Menu System System Operation
Invalid Password/Panel Timeout
If a password is entered incorrectly or is not a valid password, the panel will display an error message. You must hit ENTER or the left arrow
key and re-enter the password correctly. After ten invalid attempts, the panel will panel will lock for 30 seconds and then you can try again.
However, if the password has been forgotten, record the 20-character code displayed on the panel and contact Technical Services. After
proper authentication, the password will be supplied.
9.2.2 Main Menu Overview
The chart below is a brief overview of the Main Menu. These options are described in greater detail throughout this section of the manual.
9.2.3 Using the Menus
Panel Menus System Tests
Fire Drill Menu
Indicator Test
Walk Test-No Report
Walk Test -With Report
Communicator Test
Clear History Buffer
Point Functions
Disable/Enable Point
Point Status
Set SLC Device Address
SLC Single Device Locater
SLC Multiple Device Locater
I/O Point Control
Event History
Set Time & Date
System Information
Network Diagnostics
Network Programming
Panel Programming
Send/Receive Firmware Update
*Function Keys are only available on the RA-2000 LCD annunciator.
Type of Function Selectable Functions
Table 9.1 User Profile Selectable Panel Functions
Main Menu Options Description
1- System Tests Access to Fire Drill, Indicator Test, Walk Tests, Communicator Test, Clear History Buffer, Manual AlarmNet
Registration, and Manual Communicator Reset
2- Point Functions Enable/disable points, Point Status, SLC Single Device Locater, SLC Multiple Device Locater, and I/O Point Control
3- Event History Display event history on the LCD. See Section 9.3.3 for more information.
4- Set Time and Date Set time and date for the system
5- Network Diagnostics Ping Panel, Data Network Status, and Voice Network Status
6- Network Programming Access Learn Network, Edit Network Names, Edit Panel ID, Computer Access, Communicator Options, Voice
Options, Sync Network Options
7- Panel Programming Brings up a set of menus for programming the panel. These options are described in detail in Section 8.
8- System Information Menus to view information about the panel such as model, ID, serial number, revision, send or receive firmware
updates and feature registration activation
Table 9.2 Main Menu Options
To move through the menus: Use the up and down arrow key to move the cursor through the options in a menu. Use the
left arrow key to move to a previous menu.
To select an option: Enter the number of the option, or press ENTER if the option has the = symbol next to it.
Exit Menu Press the left arrow.
