212 HC900 Process & Safety Controller User and Installation Manual Revision 6
21 April 2017
Type
Range
Low
Range High
EU
(Reference): Corresponding
UMC800 Input type and range
NiCroSil-NiSil
0
1472
F
N 32 1472 F 23
R
-18
1704
C
R -20 1760 C 28
R
0
3100
F
R -4 3200 F 29
S
-18
1704
C
S 0 1600 C 30
S
0
3100
F
S 32 2912 F 31
T
-184
371
C
T –200 400 C 40
T
-300
700
F
T –328 752 F 41
T
-129
260
C
T -50 150 C 34
T
-200
500
F
T -58 302 F 35
W_W26
-20
2320
C
W_W26 -20 2320 C 52
W_W26
-4
4200
F
W_W26 -4 4208 F 53
W5W26
-18
2316
C
W5W26 -20 2320 C 54
W5W26
0
4200
F
W5W26 -4 4208 F 55
W5W26
-18
1227
C
n/a
W5W26
0
2240
F
n/a
Platinel
0
1380
C
PLTNL 0 1380 C 118
Platinel
32
2516
F
PLTNL 32 2516 F 119
Platinel
0
750
C
PLTNL -70 750 C 116
Platinel
32
1382
F
PLTNL -94 1382 F 117
Pt100
-184
816
C
Pt100 –200 800 C 68
Pt100
-300
1500
F
Pt100 –328 1472 F 69
Pt100
-184
649
C
n/a
Pt100
-300
1200
F
n/a
Pt100
-184
316
C
Pt100 -50 150 C 60
Pt100
-300
600
F
Pt100 -58 302 F 61
Pt500
-184
649
C
n/a
Pt500
-300
1200
F
n/a
Pt1000
-40
260
C
Pt1000 –50 400 C 120
Pt1000
-40
500
F
Pt1000 –50 752 F 121
JIS100
-200
500
C
JIS -200 500 C 78
JIS100
-328
932
F
JIS -328 932 F 79
JIS100
-200
260
C
JIS 0 100 C 72
JIS100
-328
500
F
JIS 32 212 F 73
Cu10
-20
250
C
Cu10 -20 250 C 84
Cu10
-4
482
F
Cu10 -4 482 F 85
YSI405
10
37.8
n/a
YSI405
50
100
n/a
Ohms
0
200
Ohms 0 200 86
Ohms
0
500
n/a
Ohms
0
1000
n/a
Ohms
0
2000
Ohms 0 2000 87
Ohms
0
4000
n/a
MA
4
20
mA 4 20 100
MA
0
20
mA 0 20 99
