Honeywell HC900 - Table 41 - HC900 PV Input Types and Ranges

Revision 6 HC900 Process & Safety Controller User and Installation Manual 211
21 April 2017
Environmental Conditions
Ambient
Temperature
Reference
Rated
Extreme
Transportation & Storage
F
C
77+/-5
25+/-3
32 to 140
0 to 60
32 to 140
0 to 60
-40 to 158
-40 to 70
Ambient Relative
Humidity
*45 % to 55 % RH
non-condensing
*10% to 90 % RH
non-condensing
*5 % to 90 % RH
non- condensing
*5 % to 95 % RH
non-condensing
Mechanical
Acceleration
Duration
0 g
0 ms
1 g
30 ms
1 g
30 ms
Not rated
Vibration
0 Hz
0 g
0 Hz to 14 Hz—
amplitude 2.5 mm
(peak-to-peak)
14 Hz to 250 Hz—
acceleration 1 g
0 Hz to 14 Hz—
amplitude 2.5 mm
(peak-to-peak)
14 Hz to 250 Hz—
acceleration 1 g
* Applies up to 40C
Table 41 - HC900 PV Input Types and Ranges
Type
Range
Low
Range High
EU
(Reference): Corresponding
UMC800 Input type and range
None
n/a
B
-18
1815
C
B 40 1820 C 58
B
0
3300
F
B 104 3308 F 59
E
-270
1000
C
n/a
E
-454
1832
F
n/a
E
-129
593
C
n/a
E
-200
1100
F
n/a
J
-18
871
C
J –200 870 C 4
J
0
1600
F
J –328 1598 F 5
J
-7
410
C
J 0 400 C 2
J
20
770
F
J 32 752 F 3
K
-18
1316
C
K 0 1200 C 16
K
0
2400
F
K 32 2192 F 17
K
-18
982
C
K 0 800 C 14
K
0
1800
F
K 32 1472 F 15
K
-29
538
C
K 0 400 C 12
K
20
1000
F
K 32 752 F 13
Ni-NiMo
0
1371
C
NiMo 0 1400 C 50
Ni-NiMo
32
2500
F
NiMo 32 2552 F 51
Ni-NiMo
0
682
C
n/a
Ni-NiMo
32
1260
F
n/a
NiMo-NiCo
0
1371
C
MoCo 0 1400 C 110
NiMo-NiCo
32
2500
F
MoCo 32 2552 F 111
NiMo-NiCo
0
682
C
n/a
NiMo-NiCo
32
1260
F
n/a
NiCroSil-NiSil
-18
1300
C
N 0 1200 C 24
NiCroSil-NiSil
0
2372
F
N 32 2192 F 25
NiCroSil-NiSil
-18
800
C
N 0 800 C 22
