Honeywell HC900 User And Installation Manual

Introduction
2 HC900 Process & Safety Controller User and Installation Manual Revision 6
21 April 2017
Model Selection Guide
Legacy System
Description
Model number
SIL Compatible*
Racks
4 I/O Slot Rack
900R04 – 0001
No
8 I/O Slot Rack
900R08 – 0101
No
12 I/O Slot Rack
900R12 – 0101
No
8 Slot Rack -Red. Power
900R08R – 0101
No
12 Slot Rack - Red. Power
900R12R – 0101
No
Redundant CPU Rack
900RR0 – 0001
No
Controllers
Controller C50 CPU
900C52 – 02XX-00
No
Controller C30 CPU
900C32 – 02XX-00
No
Controller C70 CPU
900C72 – 01XX-00
No
Controller C70R CPU
900C72R – 01XX-44
No
Redundancy switch module
900RSM – 0001
No
I/O Scanner - 2 Port (1 per I/O rack)
900C73R – 01XX-44
No
I/O Scanner (for remote rack)
900C53 – 02XX-00
No
Redundant Power Status Module
900PSM – 0001
No
Power Supplies
120/240VAC, 60W
900P01 – 0001
No
120/240VAC, 28W
900P02 – 0001
No
+24VDC
900P24 – 0001
NA
I/O Modules
Analog Input (8 channel)
900A01 – 0102
No
High Level Analog Input (16 channel)
900A16 – 0001
No
Analog Output, 0 to 20mA, (4 channel)
900B01 – 0201
No
Analog Output, 0 to 20mA, (8 channel)
900B08 – 0001
No
Analog Output, 0 to 20mA, (16 channel)
900B16 – 0001
No
Digital Input, Contact type, (16 channel)
900G01 – 0102
No
Digital Input, 24VDC (16 channel)
900G02 – 0102
No
Digital Input, 24VDC (32 channel)
900G32 – 0001
No
Digital Input, 120/240 VAC, (16 channel)
900G03 – 0102
No
Digital Input, 120/240VAC, 125VDC (16ch-Iso)
900G04 – 0001
No
Digital Output, Relays ( 8 channel)
900H01 – 0102
No
Digital Output, 24VDC (16 channel)
900H02 – 0102
No
Digital Output, 24VDC (32 channel)
900H32 – 0001
No
Digital Output, 120/240 VAC (8 channel)
900H03 – 0102
No
Pulse/Frequency/Quadrature
900K01 – 0101
NA
*Reference only – For the latest Hardware and firmware revision numbers can be found at:
https://www.honeywellprocess.com/library/support/Public/Downloads/HC900-
SafetyControllerModulesRevisions.zip

Honeywell HC900 Specifications

General

Series	HC900
Redundancy	Optional
Programming Language	Function Block Diagram, Ladder Logic, Structured Text
Inputs	Analog, Digital
Outputs	Analog, Digital, Relay
Display	Optional
Control	PID, Advanced Control
Power Supply	24V DC or 100-240V AC
Storage Temperature	-40°C to 85°C
Humidity	5% to 95% non-condensing
Communication Protocols	Modbus, Ethernet
