Introduction
Revision 6 HC900 Process & Safety Controller User and Installation Manual 3
21 April 2017
Description
Model number
SIL Compatible*
I/O Components
Low VoltageTerminal Block (Euro style)
900TEK – 0001
No
Low VoltageTerminal Block (Barrier Style)
900TBK – 0001
No
High VoltageTerminal Block (Euro style)
900TER – 0001
No
High Voltage Terminal Block (Barrier Style)
900TBR – 0001
No
High Density Terminal Block
900TCK – 0001
No
I/O Components
Analog Input Remote Terminal Panel (RTP)
900RTA – L001
NA
Relay Output Remote Terminal Panel (RTP)
900RTR – H001
NA
DI, DO, AO Remote Terminal Panel (RTP)
900RTS – 0001
NA
Low Voltage RTP Cable (1.0M, 3.28ft.)
900RTC – L010
NA
Low Voltage RTP Cable (2.5M, 8.2ft.)
900RTC – L025
NA
Low Voltage RTP Cable (5.0M, 16.4ft.)
900RTC – L050
NA
High Voltage RTP Cable (1.0M, 3.28ft.)
900RTC – H010
NA
High Voltage RTP Cable (2.5M, 8.2ft.)
900RTC – H025
NA
High Voltage RTP Cable (5.0M, 16.4ft.)
900RTC – H050
NA
High Density RTP Cable (1.0M, 3.28ft.)
900RTC – 3210
NA
High Density RTP Cable (2.5M, 8.2ft.)
900RTC – 3225
NA
High Density RTP Cable (5M, 16.4ft.)
900RTC-3250
NA
Filler Block Terminal Cover
900TNF – 0001
NA
Shield Terminal Strip (package of 2)
900TSS – 0001
NA
Terminal board jumpers (10, two pos jumpers)
900J02 – 0001
No
Terminal board jumpers (10, ten pos.jumpers)
900J10 – 0001
No
Manuals
Full Document set on CD
900ME1 – 00XX-XX
NA
Software
HC Designer Config. Software CD
900W01 – 00XX-XX
NA
HC Utilities Software/Documentation CD
900W02 – 00XX-XX
NA
Kits & Accessories
Redundant Power, Rack Extension Kit
900RPE – 0001
NA
Spare I/O Label Kit
51452262 – 501
NA
Replacement Battery Kit
51500638 – 501
NA
Ethernet Cable (10 feet)
51451432 – 010
NA
Ethernet Cable (20 feet)
51451432 – 020
NA
Ethernet Cross-over Cable (20 feet)
51451996 – 020
NA
Null Modem Cable
51404755 – 501
NA
Null Modem Cable used with 900C70R
50004820 – 501
NA
250 ohm Shunt Resistor Kit ( (8/pkg.)
51205995 – 501
NA
Ethernet Switching Hub (8 Ports)
50008930 – 001
NA
24 VDC Power Supply
51452041 – 501
NA
*Reference only – For the latest Hardware and firmware revision numbers can be found at:
https://www.honeywellprocess.com/library/support/Public/Downloads/HC900-
SafetyControllerModulesRevisions.zip

Honeywell HC900 Specifications

General

Series	HC900
Redundancy	Optional
Programming Language	Function Block Diagram, Ladder Logic, Structured Text
Inputs	Analog, Digital
Outputs	Analog, Digital, Relay
Display	Optional
Control	PID, Advanced Control
Power Supply	24V DC or 100-240V AC
Storage Temperature	-40°C to 85°C
Humidity	5% to 95% non-condensing
Communication Protocols	Modbus, Ethernet
