Revision 6 HC900 Process & Safety Controller User and Installation Manual 229
21 April 2017
Analog Input/Digital Input/Digital Output/Analog Output
A single DI/DO/AO-RTP and cable is used with the following modules: See page
 4-point Analog Output 229
 16-point Contact Digital Input 231
 16-point DC Digital Input 232
 16-point AC Digital Input 234
 16-point DC Digital Output 235
 8-point AC Digital Output 238
 8-point Analog Output 241
Dual DI/DO/AO-RTPs and cables are used with the following modules: See page
 16-point Analog Output 244
 16-point Analog Input 245
 32-Point DC Digital Output 248
 32-Point DC Digital Input 250
4 Point Analog Output
Step
Action
1
ATTENTION: RTP and cables are intended for permanent installation within their own enclosure.
Mount RTP cable assembly to HC900 Controller (Figure 96).
 Remove appropriate key tabs from terminal block to allow mating with the module. See page 85.
 Connect desired cable to AO module at controller. Choose from:
900RTC-L010 Remote Terminal Low Voltage Cable Assembly, 1.0 meters long
900RTC-L025 Remote Terminal Low Voltage Cable Assembly, 2.5 meters long
900RTC-L050 Remote Terminal Low Voltage Cable Assembly, 5.0 meters long
 Install AO module label onto the module connector cover.
 Connect shield drain wire to the grounding bars at the base of the HC900 rack. All field-wiring
shields must be grounded as described in the shield grounding section (page 81).
2
Mount RTP to DIN rail.
 Latch to rail. See page 253.
 Connect cable to RTP

Honeywell HC900 Specifications

General

Series	HC900
Redundancy	Optional
Programming Language	Function Block Diagram, Ladder Logic, Structured Text
Inputs	Analog, Digital
Outputs	Analog, Digital, Relay
Display	Optional
Control	PID, Advanced Control
Power Supply	24V DC or 100-240V AC
Storage Temperature	-40°C to 85°C
Humidity	5% to 95% non-condensing
Communication Protocols	Modbus, Ethernet
