Heat Rise De-rating
The HC900 is rated to operate at 60
o
C. However, for maximum reliability, the following guidelines should
be observed for applications above 52
o
C.
1. Locate lower-power modules (Analog Input, Contact Input, etc) beside the Controller/Scanner Module,
and keep higher-power modules (AC Output, AC Input, etc) away from it. For power consumption of
each module, see Table 4.
2. For 240 Vac applications and temperatures above 56
o
C, or 264Vac, 52
o
C, de-rate the number of ON
inputs per AC input module. (See AC Input de-rating data, see Figure 27.)
3. Limit the number of Analog Output modules to a maximum of 10 per rack. (see Figure 28)
Table 4 – Power Applied, by Module Type
Module
HC900 Hardware
Power (Watts)
Field Power
(Watts)
Total Power
(Watts)
Controller C30 and C30S
6.0
0.0
6.0
Controller C50 and C50S
6.0
0.0
6.0
Controller C70 and C70S
7.1
0.0
7.1
Controller C75 and C75S
7.8
0.0
7.8
Redundancy switch module (RSM)
0.1
0.0
0.1
Power Status Module (PSM)
0.1
0.0
0.1
Scanner 1 Port (S50/S50S)
3.9
0.0
3.9
Scanner 2 Port (S75/S75S)
5.0
0.0
5.0
Analog Input (Universal)
0.8
0.0
0.8
Analog Input (High level)
1.6
0.0
1.6
Analog Output (4 points)
5.1
0.0
5.1
Analog Output (8 pts. internal 24V)
9.4
0.0
9.4
Analog Output (8 pts. external 24V)
1.1
8.3
9.4
Analog Output (16 pts. internal 24V)
18.3
0.0
18.3
Analog Output (16 pts. external 24V)
1.7
16.6
18.3
Contact Input
1.6
0.0
1.6
Relay Output
3.0
0.0
3.0
16 pt DC In (@ 24V)
0.7
2.6
3.3
16 pt DC In (@ 32V)
0.7
5.1
5.7
32 pt DC In (@ 24V)
1.1
3.1
4.2
32 pt DC In (@ 32V)
1.1
5.1
6.2
16 pt DC Out
1.7
1.2
2.9
32 pt DC Out
1.2
1.8
3.0
AC In (@120V)
0.7
1.9
2.6
AC In (@240V)
0.7
7.7
8.3
AC/DC In
0.7
7.7
8.3
AC Out
1.1
12.0
13.1
PFQ
6.7
0.1
6.8
