Introduction
4 HC900 Process & Safety Controller User and Installation Manual Revision 6
21 April 2017
Operator Interface
Description
Model number
900 Control Station 10” Screen
900CS10 – xx
900 Control Station 15” screen
900CS15 – xx
Station Designer Software
900SDS – 12-44-00
OI Accessories & Kits
CompactFlash Memory Module
50040636 – 002
USB Programming Cable
50038817 – 001
10” Screen Protective Films (10)
50038816 – 501
10” Replacement Backlight
50038818 – 501
10” Replacement Touch Screen Assy.
50038820 – 501
10” Mounting plate adapter for 1042 replacement
50039118 – 501
24 VDC Power Supply for 10”
51452041 – 501
900 Control Station User Manual (paper)
51-52-25-148
15” Screen Protective Films (10)
50038816 – 502
24VDC Power Supply for 15”
50047098 – 001
GSM/GPRS Cellular Modem Kit
50047099 – 501
New Non-SIL System
Description
Model number
SIL Compatible*
Controllers
Controller C30 CPU
900C30 – 0360-00
No
Controller C50 CPU
900C50 – 0360-00
No
Controller C70 CPU
900C70 – 0360-00
No
Controller C75 CPU
900C75 – 0360-00
No
I/O Scanner – 2 Port (1 per I/O rack)
900S75 – 0360-00
No
I/O Scanner – 1 Port (1 per I/O rack)
900S50 – 0360-00
No
Power Supplies
120/240 VAC. 60W
900P01-0101
No
120/240 VAC, 28 W
900P02-0101
No
24 VDC, 60 W
900P24-0101
No
*Reference only – For the latest Hardware and firmware revision numbers can be found at:
https://www.honeywellprocess.com/library/support/Public/Downloads/HC900-
SafetyControllerModulesRevisions.zip

Honeywell HC900 Specifications

General

Series	HC900
Redundancy	Optional
Programming Language	Function Block Diagram, Ladder Logic, Structured Text
Inputs	Analog, Digital
Outputs	Analog, Digital, Relay
Display	Optional
Control	PID, Advanced Control
Power Supply	24V DC or 100-240V AC
Storage Temperature	-40°C to 85°C
Humidity	5% to 95% non-condensing
Communication Protocols	Modbus, Ethernet
