Introduction
Revision 6 HC900 Process & Safety Controller User and Installation Manual 5
21 April 2017
SIL System
Description
Model Number
SIL Compatible*
Racks
4 I/O Slot Rack
900R04 – 0200
Yes
8 I/O Slot Rack
900R08 – 0200
Yes
12 I/O Slot Rack
900R12 – 0200
Yes
8 Slot Rack -Red. Power
900R08R – 0200
Yes
12 Slot Rack - Red. Power
900R12R – 0200
Yes
Redundant CPU Rack
900RR0 – 0101
Yes
Controllers
Controller C30 CPU – SIL
900C30S – 0360-00
Yes
Controller C50 CPU – SIL
900C50S – 0360-00
Yes
Controller C70 CPU – SIL
900C70S – 0360-00
Yes
Controller C75 CPU – SIL
900C75S – 0360-00
Yes
I/O Scanner – 1 Port (1 per I/O rack) - SIL
900S50S – 0360-00
Yes
I/O Scanner – 2 Port (1 per I/O rack) - SIL
900S75S – 0360-00
Yes
Documentation
Full Document set on CD – SIL
900ME1S – 0060-00
Yes
Full document set, SIL hard copy –
English
900ME2S – 0060-00
Yes
I/O Modules
Analog Input
(8 channel)
900A01-0202
Yes
Analog Input Hi level (16channel)
900A16-0101
Yes
Analog Output, 0 to 20mA, (4 channel)
900B01-0301
Yes
Analog Output, 0 to 20mA, (8 channel)
900B08-0202
Yes
Analog Output, 0 to 20mA, (16 channel)
900B16-0202
Yes
Digital Input, Contact type, (16 channel)
900G01-0202
Yes
Digital Input, 24VDC
(16 channel)
900G02-0202
Yes
Digital Input, 120/240 VAC, (16 channel)
900G03-0202
Yes
Digital In, 120/240 VAC, 125VDC
(16 channel-Isolated)
900G04-0101
Yes
Digital Input, 24VDC
(32 channel)
900G32-0101
Yes
Digital Output, Relays
(8 channel)
900H01-0202
Yes
Digital Output, 24VDC
(16 channel)
900H02-0202
Yes
Digital Output, 120/240 VAC (8 channel)
900H03-0202
Yes
Digital Output, 24VDC (32 channel)
900H32-0102
Yes
Pulse/Freq/Quad (4chan, 1Quad)
900K01-0201
May be used in Safety systems on
the Process Worksheet ONLY.

Honeywell HC900 Specifications

General

Series	HC900
Redundancy	Optional
Programming Language	Function Block Diagram, Ladder Logic, Structured Text
Inputs	Analog, Digital
Outputs	Analog, Digital, Relay
Display	Optional
Control	PID, Advanced Control
Power Supply	24V DC or 100-240V AC
Storage Temperature	-40°C to 85°C
Humidity	5% to 95% non-condensing
Communication Protocols	Modbus, Ethernet
