Configuring Network Settings | 107
800-16694 - A - 04/2014
Configuring UPnP Settings
Universal Plug and Play (UPnP) lets the DVR to seamlessly discover other devices on the
network and establish functional network services for data sharing, and communications. For
example, if you want to enable a fast WAN connection via a router, you should configure UPnP
on the DVR.
To enable UPnP on the DVR, you will first need to enable UPnP on the router that your device is
connected to. When the network working mode of the DVR is set as multi-address, the Default
Route should be in the same network segment as the LAN IP address of the router.
To configure UPnP settings:
1. Go to Menu > Settings > Network > UPnP.
2. Select the Enable UPnP check box to enable Universal Plug and Play on your DVR.
3. Set Mapping Type to Auto or Manual.
When Auto is selected, the mapping ports are automatically assigned by the router.
When Manual is selected, the mapping ports must be configured manually.
4. If the mapping type is set to Manual, click the Edit button to manually configure the
external port numbers for Server Port, HTTP Port, and RTSP Port.
5. To view the latest status of the port mapping, click Refresh.
6. Click Apply to save your settings.
