Controlling a PTZ Device | 53
800-16694 - A - 04/2014
Calling Patterns
To call a pattern in live view mode:
1. Click on a channel to display the quick setting
toolbar (see
Quick Setting Toolbar, page 35
).
2. On the toolbar, click the PTZ Control button .
3. In the on-screen PTZ control interface, under
Camera, select your PTZ camera from the list.
4. Click Pattern to view the list of patterns, and then
click the pattern you want to call.
5. Click the start button to start the pattern. To
stop the pattern, click the stop button .
To call a pattern in the PTZ configuration interface:
1. Go to Menu > Camera > PTZ > More Settings (or click Configuration in the PTZ
control interface).
2. Select the pattern you want to call from the drop-down list, and then click the
Run
button
to call the pattern. To stop the pattern, click the
Stop
button.
