90 PC45 Series Printer User Guide
RFID
To view these settings:
• From the printer Main Menu, select Settings > Printing > RFID.
• From the printer web page, click Configure > Printing > RFID.
System Settings
General System
To view these settings:
• From the printer Main Menu, select Settings > System Settings > General.
• From the printer web page, click Configure > System Settings > General.
RFID Setting Description Default
Retries Sets the number of RFID Labels the printer tries to access
after it fails to read or write to an RFID Tag. Range is 1 to 10.
0
Void Texts Sets the text that is printed on each label that has a faulty
RFID tag. Range is 1 to 16 characters.
VOID
RFID Tag
Position
Sets the distance the label is moved to align the RFID tag over
the antenna to allow a successful read and write operation.
Unit of measurement is defined in the Unit of Measure
parameter. Range is -10000 to +10000
0 dots
Output Power Sets the amount of field strength the antenna applies to
communicate with the RFID tag.
18
RFID Tag Type Select the type of RFID tag used in the printer. Read and
Write
General System Setting Description Default
System Name Sets the network identification name (WINS
name) of the printer.
Printer model
number and serial
number.
System Location Sets the location of the printer. Empty string
System Contact Sets the name of the printer administrator. Empty string
XML Response Mode Determines if the printer provides XML
responses to printing requests (over Telnet
and HTTP).
False
Display Language (LCD printers only.) Selects the language the
printer uses to display text on the screen.
English
Display Language (Web
Page)
Selects the language the printer uses to
display text on the web page.
English
Keyboard Input Selects the language of the external keyboard
that is connected to the printer.
U.S./U.K.
Time Sets the current time. System time
Date Sets the current date. System date
