PC45 Series Printer User Guide 75
SPECIFICATIONS AND
ADDITIONAL RESOURCES
Specifications and Resources
1. Go to www.sps.honeywell.com.
2. Type PC45 in the search box and then press Enter.
3. Click on the product link in the search results.
4. Select one of the following tabs:
• Specifications
View Printer features, Software, Hardware information, and environmental
specifications.
• Resources or Documents
View and download available product documentation. For example, Data
Sheet, Accessory Guide, Quick Start Guide, User Guide, Regulatory
Information, and other product documentation.
Media Specifications
For PC45d Printer
Parameter Specification
Media Roll Width 0.59in to 4.65in (15mm to 118mm)
Maximum Print Width 203dpi: 4.25 in(108mm)
300dpi: 4.12 in (106mm)
Label Roll Diameter (max.) 5in (127mm)
Label Length (min.) Printer only: 0.25in (6.35mm)
With Cutter Module: 1in (25.4mm)
With Self-Strip Module: 0.5in (12.7mm)
Media Thickness 2.5mil to 8mil (0.06mm to 0.2mm)
