PC45 Series Printer User Guide 89
Print Quality
To view these settings:
• From the printer Main Menu, select Settings > Printing > Print Quality.
• From the printer web page, click Configure > Printing > Print Quality.
Cutter
To view these settings:
• From the printer Main Menu, select Settings > Printing > Cutter.
• From the printer web page, click Configure > Printing > Cutter.
Print Quality
Setting
Description Default
Print Speed Sets how fast the printer prints labels. The unit of measure is
defined in the Unit of Measure parameter.
102mm/sec
Media
Sensitivity
Sets the level of sensitivity of the media to the printhead heat
for media and ribbon.
High (TTR)
Very Low (DT)
Darkness Sets the image darkness for media and ribbon. Adjust this
parameter with the Media Sensitivity parameter. Range is 1 to
100.
55 (TTR)
75 (75)
Contrast Adjusts the blackness of the printing on the label in 2%
increments from -10% to +10%.
+0%
Label Rotation Rotate the label in 0 (no rotation), 90, 180, 270 degree in
clockwise direction.
0 deg
Cutter Setting Description Default
Cutter Control Determines if the cutter automatically cuts labels or partially
cuts or if you must manually send a command each time you
want to cut a label.
Manual
Cut Interval Sets the interval (number of labels) after which cut operation
has to be performed, enabled only in automatic cutter control
mode.
1
Cut After Feed Enables the cutter to cut after feeding the media. Disable
