Honeywell PC45 Series

76 PC45 Series Printer User Guide
For PC45t Printer
Command Languages and Simulator Support Features
• Fingerprint
• Direct Protocol
•ESim
•IPL
•ZSim
•DPL
• Smart Printing C#
• Direct PDF Printing
Print Sensors
• Dual label gap/tag notch
• Black mark
• Printhead lift
• Ribbon present/end
•Ribbon low
•Label taken (optional)
Parameter Specification
Media Roll Width 0.59 to 4.65in (15 to 118mm)
Maximum Print Width 203dpi: 4.25 in(108mm)
300dpi: 4.12 in (106mm)
Label Roll Diameter (max.) 5in (127mm)
Label Length (min.) Printer only: 0.25in (6.35mm)
With Cutter Module: 1in (25.4mm)
With Self-Strip Module: 0.5in (12.7mm)
Media Thickness 2.5 to 8mil (0.06 to 0.2mm)
Media Roll Width 0.59in to 4.65in (15 to 118mm)
Ribbon Width 1 to 4.33 in (25.4 to 110 mm)
Ribbon Roll Max. Diameter 2.68 in (68 mm)
Ribbon Core Width 4.37 in (111 mm)
