Chapter 5 General Operation
Honeywell Confidential: Use or disclosure of information on this page is subject to the restrictions on the title page.
13841 Rev A
102
engines necessarily require bigger and heavier propellers, this
method works well for setting weight sensitivity.
Enter this information, using the second Propeller Balance Setup
screen, as shown below.
Use the following general checklist to make sure the user is
working with the correct horsepower/weight sensitivity settings:
The default setting for HP ENGINE is -100.
After the user has entered the correct horsepower, note the
sensitivity number displayed beneath the SET
SENSITIVITY line.
Repeated key presses of the context key scroll through the
available horsepower ranges and their attendant sensitivities.
The Vibrex unit learns the response to the first weight
change and corrects the sensitivity to one that is appropriate
for the propeller being balanced.
NOTE: Occasionally, the user may need to be conservative
on the first balance adjustment. This condition could
? PROPELLER BAL SETUP
< -100 > HP ENGINE
SET SENSITIVITY
35.00 G/IPS @ 12:00
AUTO CORRECTION<ON>
if ok, push START
SELECT TO ENTER
CORRECT ENGINE
HORSEPOWER RANGE
OR
SELECT TO ENTER
CORRECT ENGINE
SENSITIVITY SETTINGS
SELECT TO SWITCH
AUTOCORRECTION
FEATURE ON OR OFF
