Chapter 2 System Overview
Honeywell Confidential: Use or disclosure of information on this page is subject to the restrictions on the title page.
13841 Rev A
12
powered up, so the unit only does an abbreviated test for short-
term power-down/power-up cycles.
2.2.2 Vibrex 2000 Plus
Enhancements
The Vibrex 2000 Plus model represents a significant
performance increase over the Vibrex 2000 (Part Number 13590-
2 and earlier). In addition to all existing Vibrex 2000 benefits
features, and capabilities, the Vibrex 2000 Plus system offers the
following extended capabilities.
An increase in maximum spectrum frequency from 24,000
RPM to 600,000 RPM (10 kHz)
A graphic spectrum viewing mode
An extended balance frequency range from 120 RPM to
30,000 RPM
Support for running up to four propeller balance jobs in
parallel operation (can suspend one then jump out and start
another)
Four times the memory, allowing more data to be saved (1
Mb)
The ability to store balance jobs, adjustments, sensitivities,
spectra, and balance measurements in the instrument’s
memory and archive them on a PC
Storage of firmware in the instrument’s Flash memory,
facilitating software upgrades and enhancements; there is no
longer any need to open the instrument for this purpose
