Chapter 5 – General Operation
Honeywell Confidential: Use or disclosure of information on this page is subject to the restrictions on the title page.
13841 Rev A
199
5.8.4.2
Displaying Cursor Data
The Vibrex 2000 Plus also allows the user to display specific
data associated with the current cursor position. Do this action,
as follows:
1. In the Spectrum Viewer screen, place the cursor on the
desired peak.
2. Press the ? context key. The Cursor Data screen displays
(see below).
This screen gives the user specific vibration data on the current
cursor position.
" " LIST 1
17JAN00 16:54:46 1A
0- 30,000 RPM
CURRENT CURSOR DATA
0.86 IPS 15300 RPM
1.1 mils Pk-Pk
3.6 Gs 255.0 Hz
