Quick Reference Guide
Honeywell Confidential: Use or disclosure of information on this page is subject to the restrictions on the title page.
13841 Rev A
xi
Quick Reference Guide
This guide provides a quick-start reference for the Vibrex 2000
and Vibrex 2000 Plus and the Enhanced Vibrex 2000 Plus
Digital Dynamic Balancer systems. The term Vibrex unit refers
to all these systems. Throughout this document they may also be
referred to V2K, V2K+ and EV2K+ respectively.
To order this User Guide use Part Number 768-13841-X
(Latest Dash number).
Propeller Balance (Generic)
Propeller Balance, Run No. 1
Install the photocell, velocimeter(s), and reflective tape on
the propeller to be balanced.
Turn on the Vibrex unit.
Select Propeller Balance from the Main Menu
screen.
Ensure the propeller input is plugged into channel No. 1 and
A and any other propeller or velocimeter in the other
channel. Press START.
Select the engine horsepower, then press START.
Operate the propeller at the desired balance RPM. When the
RPM is steady, press START.
When the Vibrex unit has finished collecting data, press
START.
If the reading is not acceptable (greater than 0.2 IPS),
press START.
