Honeywell Vibrex 2000 - Appendix C: EV2 K+ Fastrak Configurations

Honeywell Confidential: Use or disclosure of information on this page is subject to the restrictions on the title page..
13841 Rev A
253
Appendix C: EV2K+
FasTrak Configurations
Config Name
Rotor
Diameter
(mm)
Tracker
Sensitivity
(mm/Rev)
Adjustment Sensitivity
Regime
Sens
A-109E Gnd Factory
11000
198882
Gnd
6.5 flats/in
A-109E Hvr Factory
11000
198882
Hvr
4.98 flats/in
A-109E 140 Factory
11000
198882
140
KIAS
7.52 deg/in
A-119 Gnd Factory
18900
198882
Gnd
5.43 ticks/in
A-119 Hvr Factory
18900
198882
Hvr
5.09 ticks/in
A-119 140 Factory
18900
198882
140
KIAS
6.11 deg/in
AS-332 Gnd Factory
15602
219515
Gnd
29.4 notches/in
AS-332 Hvr Factory
15602
219515
Hvr
32.86 notches/in
AS-332 130 Factory
15602
219515
130
KIAS
11.77 deg/in
AS-350 Gnd Factory
(350B/B1/355)
10690
180000
Gnd
7.57 flats/in
AS-350 Hvr Factory
10690
180000
Hvr
5.75 flats/in
AS-350 120 Factory
10690
180000
120
KIAS
2.79 flats/in
AS-365 Gnd Factory
11939
157719
Gnd
3.84 flats/in
AS-365 Hvr Factory
11939
157719
Gnd
4.34 flats.in
AS-365 130 Factory
11939
157719
130
KIAS
7.40 deg/in
AW-139 Gnd Factory
13800
198790
Gnd
1.89 flats/in
AW-139 Hvr Factory
13800
198790
Hvr
1.46 flats.in
