Chapter 5 – General Operation
Honeywell Confidential: Use or disclosure of information on this page is subject to the restrictions on the title page.
13841 Rev A
136
If STROBEX is selected, proceed the same as V2K/V2K+
Strobex in paragraph 5.5.1.2, “Main Rotor Track (Strobex)
(EV2K+)”.
If FasTrak is selected, proceed to the next section.
5.5.1.3
Main Rotor Track (FasTrak®) (EV2K+
Heli Only)
The EV2K+ Heli is pre-programmed with many helicopter main
rotor track configurations that match the helicopter balance
models. The list can be found in Appendix C. Do main rotor
FasTrak
®
track operations as follows:
1. Install a single interrupter on the rotating swashplate, in the
same way as the user would for any track-and-balance
operation.
NOTE: If the aircraft installation normally uses a double
interrupter with the other single interrupters, remove the
double interrupter and other single interrupters so there is
only one single interrupter on the rotating swashplate.
2. Mount the magnetic pickup, in the same way as the user
would normally.
3. Connect the magnetic pickup cable to the channel A
connector of the Vibrex unit.
► <A-109E Gnd Factory >
► STROBEX
Tracking 4 Blades
► FasTrak
► CHANGE TRACK CONFIG
To Next Page
