Page #151 background imageLoading...
Page #151 background image
Chapter 5 General Operation
Honeywell Confidential: Use or disclosure of information on this page is subject to the restrictions on the title page.
13841 Rev A
135
Blade tracking is accessed using the TRACK key under the
TRACK & BALANCE menu (as opposed to the V2K/V2K+
STROBEX TRACK key).
Both Strobex and FasTrak
®
configurations are factory preset
for many helicopter models. These can be recalled and saved
under new configuration names. The first time the TRACK
key is pressed the user is prompted for one of these
configurations as shown below:
Use the and keys find a configuration, then press the
START key to select the desired configuration. You can save
up to 25 user selected configurations.
NOTE: If you do not see your desired configuration, select
the closest one as it can be edited later. The configurations
include number of blades, rotor diameter, tracker and
adjustment sensitivities.
The EV2K+ track menu appears as follows as shown below.
At this point, either STROBEX or FasTrak tracking can be
selected.
= ADD TRACK CONFIG =
Select from Factory
Configurations
(Used:00 of 25)
PREVIOUS
<A-109E Gnd Factory>
NEXT
to add, push START
