Chapter 5 – General Operation
Honeywell Confidential: Use or disclosure of information on this page is subject to the restrictions on the title page.
13841 Rev A
179
paragraph 5.6.5, “Removing and Editing Models and
Charts”).
5.6.4 Job Selection
The balancing steps can be grouped together into a series of runs
called jobs. (They are also called sessions on the printouts.)
During the course of the balance session you may want to turn
off the unit to conserve battery power (or it may power off itself
with 10 minute auto-power-off option). When the unit is
powered back on, a JOB SELECTION menu will be displayed if
you are in the middle of a job and the HELICOPTER BALANCE
main menu key is pressed. This allows you to continue a current
job or start a new one. Note that up to four jobs can be worked
simultaneously. For example, both a main and tail rotor can
worked on the ground at the same time.
Note: The job selection screen for the EV2K+ series works
differently than it does for the V2K and V2K+
series.Normally, you would just press START to continue on
the job you were on when you powered off. Otherwise, press
the COMP: key to select a different component, then press
START.
? JOB SELECTION
A-109EPower
► START NEW JOB
Job 1 15NOV14 10:00
► COMP:<MR Side Trkr>
Run 1 [ANNOTATE]
► <CONTINUE JOB>
to do, push START
To Next Page
