From this screen, the user has the following options:
• Press ANNOTATE to store and annotation with the
current measurements.
• Press REDO MEAS to retake the current
measurements.
• Press GO BACK to cancel and erase the current
measurements.
• Press START to save the current measurements and
continue with the program.
6. Plot the readings on the appropriate chart at the intersection
of clock angle and IPS. Follow the fine lines perpendicular
to the heavy borders of the chart.
7. Read the changes specified on the heavy border and apply
these changes to the rotor system.
8. When the user is finished, press the GO BACK key as many
times as necessary to return to the Main Menu screen.
5.5.3 Using the Rotor Protractor
By way of a typical example, this section explains how to use the
Honeywell Rotor Protractor for balancing helicopter rotors.
WHAT DO YOU WANT TO
DO WITH MEAS 3 ?
► ANNOTATE MEAS 3
► REDO MEAS 3
cancel with GO BACK
save with START

Honeywell Vibrex 2000 Specifications

General

Frequency Range	10 Hz to 1 kHz
Power Supply	9V battery
Measurement Range	0.1 to 199.9 mm/s RMS
Accuracy	±5% ±2 digits
Display	LCD
Operating Temperature	0°C to 50°C
