Chapter 5 General Operation
Honeywell Confidential: Use or disclosure of information on this page is subject to the restrictions on the title page.
13841 Rev A
134
8. Enter the number of blades the user wants to track in the
Number of Blades screen.
9. The Strobex Track screen illustration below shows the
available tracking options.
NOTE: With the BLADE SPREAD key set to <ON>, the
SPREAD FACTOR key becomes active. In this case, the
user can set the spacing of the blades by pressing this
context key until the user obtain a correct viewing spread.
With the BLADE SPREAD key <OFF>, the blades are
superimposed on each other.
10. When the user is finished, press the GO BACK key as many
times as necessary to return to the Main Menu screen.
5.5.1.2
Main Rotor Track (Strobex) (EV2K+)
Strobex tracking using the EV2K+ works the same as for the
V2K and V2K+ as described in paragraph 5.5.1.1, “Main Rotor
Track (Strobex) (V2K and V2K+) except that the lead in menus
are configured slightly differently to accommodate the FasTrak
®
option as described in paragraph 5.5.1.3.
► BLADE SPREAD < ON>
► SPREAD FACTOR <2>
► NUMBER OF BLADES<3>
0 RPM FRM CH<A>
pull strobe trigger
BLADE SPREAD
TOGGLE
ENTER THE SPREAD
FACTOR
DISPLAYS LIVE RPM
READING FROM THE
DESIGNATED
CHANNEL
