Chapter 5 – General Operation
Honeywell Confidential: Use or disclosure of information on this page is subject to the restrictions on the title page.
13841 Rev A
133
135M-10, -10A, -10B, -10C and -12
NOTE: The Strobex does not operate on a 12V battery but
does work on an active (charging) 12-Vdc buss. The
voltage required to operate the Strobex is approximately
13.5V.
7. From the Main Menu screen, press the TRACK & BALANCE
context key to acquire a track reading. The Track and
Balance screen displays (see below).
Press the STROBEX TRACK context key. While the rotors are
turning, the magnetic pickup RPM displays in the lower left of
the Vibrex unit screen.
► ACQUIRE BAL CH:1A
► ACQUIRE BAL CH:2A
► STROBEX TRACK
► CHANGE BAL CHANNELS
PRESS TO START
COLLECTING DATA
PRESS TO BEGIN
STROBE TRACKING
