Chapter 6 – Maintenance
Honeywell Confidential: Use or disclosure of information on this page is subject to the restrictions on the title page.
13841 Rev A
219
6.3.5.2
Instrument Test Procedures for the
Vibrex 2000 and Vibrex 2000 Plus
The following tests provide the highest confidence that the
instrument is accurately measuring the incoming sensor signals.
6.3.5.3
Approach:
Signals from a calibrated source will be measure at start, mid,
and end band frequencies of the filters used and compared to
insure they meet specifications. In addition, a mid band signal
will be measured for amplitude, phase, and frequency response
and compared to specification.
All the above testing will be repeated for each of the 2 signal
paths.
Test Equipment:
HP 8904A
Signal
Generator
10 mV to 5 VAC (+/-0.1%),
distortion plus noise less
than -60 dB, sync to sine
signal phase relation
ship180 degrees
