Chapter 6 – Maintenance
Honeywell Confidential: Use or disclosure of information on this page is subject to the restrictions on the title page.
13841 Rev A
221
Adjust the amplitude of the sinewave on channel 1
so that 13.44 Vrms (+/- 0.01 Vrms) is shown on the
True RMS meter.
5. Press “TRACK & BALANCE” from the main menu of
the EUT.
6. Acquire a balance measurement on channel 1A, and
record the measurement parameters on the data sheet.
7. Press Spectrum Analysis from the main menu.
8. Complete the following table by adjusting the EUT
maximum frequency, the signal generator frequency and
the sinewave amplitude on the True RMS meters as
listed, and acquire a spectrum. Record the peak value in
the table.
6.3.5.5
For The Vibrex 2000 (Basic)
Complete steps 4 through 8 and fill out the following table:
NOTE: For the 13590-2, there is no need to repeat the test
on channel 2.
True RMS
Meter
Amplitude
(MV)
Vibrex
2000 Peak
(IPS)
Channel 1
Specification
(assumes 5%
for True
RMS meter)
0.90 <X<
1.11 11:30 -
12:30, 2400
RPM +/-3.6
