Chapter 4
4.0
INSTALLATION
This chapter gives basic information on equipment and other
materials for using the Vibrex 2000 and Vibrex 2000 Plus
Digital Dynamic Balancer/ Analyzer systems, as well as general
installation guidelines. Chapter 4 contains the following sections:
4.1 Installation: Introduction ............................................ 53
4.2 Vibrex 2000 Basic Equipment ..................................... 54
4.3 Vibrex 2000 Plus Equipment ....................................... 62
4.4 General Installation .................................................... 71
4.5 Sample Installations .................................................... 82
4.1 Installation: Introduction
The Vibrex 2000 and Vibrex 2000 Plus accept the following
types of transducer inputs:
