Chapter 3 – Getting Started
Honeywell Confidential: Use or disclosure of information on this page is subject to the restrictions on the title page.
13841 Rev A
36
Velocimeter No. 4
(902-18701-2)
3.3 Printing Data
The Vibrex 2000 and Vibrex 2000 Plus allow the user to print
hard-copy readouts of collected data or status information. The
systems print through an RS-232 serial port on the connector
subpanel. Because of the large selection of serial printers, it is
impossible to address every setup for every printer. For details,
refer to any appropriate PC and/or printer manual that pertains to
the user’s computer system.
3.3.1 Direct Serial Printing
To connect the Vibrex unit to a Seiko Model DPU-414 printer,
connect the nine-pin DBA female cable that terminates against a
9- to 25-pin male adapter. Use an adapter that has the No. 5 pin
of the 9-pin connector switched to the No. 7 pin of the 25-pin
connector.
This switching can occur on the adapter or in the 9- to 9-pin
cable or in the 9- to 25-pin connector. This type of setup works
for most other serial printers as well.
