Chapter 5 – General Operation
Honeywell Confidential: Use or disclosure of information on this page is subject to the restrictions on the title page.
13841 Rev A
137
4. Install FasTrak
®
and mounting bracket as per Application
Guide for that model.
5. Connect FasTrak
®
cable from FasTrak
®
to magnetic pickup
cable to the channel B connector of the Vibrex unit.
6. Follow instructions in paragraph 5.5.1.3 to select tracker
configuration and enter the track menu.
7. Press the FasTrak key. The following menu shown below
appear. The user should verify the tracker settings match the
given helicopter model.
8. Use the Averaging key to select the amount of rotor
rotations used to average the track readings (the default is
HIGH).
HIGH averaging: 40 rotor rotations.
MEDIUN averaging: 24 rotor rotations.
LOW averaging: 16 rotor rotations. Low averaging
returns a faster result and can be used to repeatedly
acquire data to access the variability of the track data.
9. Press the START key. An input verification screen will
appear as shown below. The user should verify that the RPM
is stable and TRK DATA is relatively stable.
Rotor Diameter
7828 mm
Tracker Sensitivity
19882 mm/REV
Adjmnt Sensitivity
6.50 flats /IN
► Averaging <HIGH>
if ok, push START
To Next Page
