Honeywell Vibrex 2000 User Manual

Chapter 5 – General Operation
Honeywell Confidential: Use or disclosure of information on this page is subject to the restrictions on the title page.
13841 Rev A
198
In this screen, the <RPM PEAK IPS> context key becomes the
CYCLE VIEW (icon) key. These keys have the same function.
Use the Arrow keys to move the cursor position.
See Section 5.8.2 “Collecting Spectral Data” for detailed
information on these screens. All other spectrum features with
the Vibrex 2000 Plus operate in the same way as they do with
the Vibrex 2000 model.
FULL SPECTRUM
VIEW
CURSOR
POSITION
SET ZOOM AREA IDENTIFIED
BY DOTTED LINE
CYCLE VIEW
CONTEXT KEY
ZOOMED
AREA VIEW
0.86 IPS 15300 RPM
