Chapter 5 – General Operation
Honeywell Confidential: Use or disclosure of information on this page is subject to the restrictions on the title page.
13841 Rev A
115
An X-mark displays on a better/worse scale bar, showing the
level of balance the user has achieved (see above). In addition to
the bar graph, there is a text label under the graph that indicates
the general balance and vibration level achieved (good in the
example above).
Read the Balance Quality graph, as follows:
Anything better than or equal to acceptable means the
propeller meets the balance guidelines given in The Smooth
Propeller.
The label unacceptable means the balance reading is higher
than the recommended 0.2 IPS.
The label warning indicates the propeller has a balance
reading over 1.2 IPS. The user must investigate the reason
for an IPS reading higher than 1.2 IPS before trying to
balance the propeller.
PROP BALANCE QUALITY
BETTER |==X===| WORSE
0.15-->good
► DONE
► INSTALL PERMANENTLY
to solve, push START
MEASURED
IMBALANCE IN IPS
