Chapter 5 – General Operation
Honeywell Confidential: Use or disclosure of information on this page is subject to the restrictions on the title page.
13841 Rev A
142
configuration to be saved under the same name, a new name
or removed. To save changes all three menus must be
followed to SAVE CONFIG AS menu. See below:
Press the REMOVE CONFIG key to remove the currently
selected user configuration. Note that factory default
configurations cannot be removed.
Press the ADD FACTORY CONFIG key add a factory
configuration. This is done exactly the same as when the
TRACK menu is first entered as per paragraph 5.5.1.2.
Up to ten user configurations may be added.
2. Use TRACK CONFIG menus 2 and 3 to edit the parameters
as desired.
Rotor Blades: Selects the number of main rotor blades.
ROTOR DIAMETER: Change the main rotor diameter (in
mm). This parameter only affects the lead-lag
measurements. Increasing the diameter linearly increases
the computed lead-lag.
TRACKER SENSITIVITY: Change the tracker sensitivity
(in mm/REV). This parameter affects the blade track
height. The factory number is derived from calculations
based on rotor geometry and FasTrak
®
mounting
position and is calibrated to observed Strobex readings.
? TRACK CONFIG 1 of 3
A-109E Gnd Factory
► REMOVE CONFIG
► ADD FACTORY CONFIG
► <4> Rotor Blades
to 2 of 3, push START
To Next Page
