Chapter 5 – General Operation
Honeywell Confidential: Use or disclosure of information on this page is subject to the restrictions on the title page.
13841 Rev A
191
The example shown above is for the Vibrex 2000, but, with
minor differences, both units display the same screen.
2. Select the appropriate channel by pressing the CHANNEL
context key.
3. Select the per-revolution (frequency) input by pressing the
AZIMUTH context key. The default is one per revolution.
NOTE: The use of a one-per-revolution azimuth signal is
not required to obtain a spectrum, but its value in
separating harmonically related peaks from other
unrelated peaks is useful.
4. Select the range of interest (active orders) by pressing the
0-<24,000>RPM (Vibrex 2000) or 0-<600,000>RPM
(Vibrex 2000 Plus) context key. See Section 5.6.1.1
“Ranging Feature” for details.
=== SPECTRUM SETUP===
<#1> VIB SENSOR
<A> AZIMUTH SENSOR
0-<24,000> RPM
if ok, push START
SELECT TO ENTER
VELOCIMETER
SETUP
SELECT TO ENTER
SETUP FOR
PHOTOCELL OR
MODEL 3030
MAGNETIC PICKUP
SELECT TO ENTER
AZIMUTH RPM
RANGE
To Next Page
