Chapter 6 Maintenance
Honeywell Confidential: Use or disclosure of information on this page is subject to the restrictions on the title page.
13841 Rev A
223
5,000 Hz
300,000
13.44
0.85 <X<
1.18
10,000 Hz
600,000
13.44
0.85 <X<
1.18
Move the vibration and azimuth cables to channels 2 and B
respectively. Repeat steps 4 through 8 and fill out the following
table:
Signal Gen
Frequency
(Hz)
Vibrex
2000 Max
RPM
True RMS
Meter
Amplitude
(VMS)
Vibrex
2000 Peak
(IPS)
Channel 2
Specification
(assume 5%
for True
RMS meter
40 Hz
Balance
13.44
0.90 <X<
1.11 11:30 -
12:30, 2400
RPM +/- 3.6
5 Hz
1,200
13.44
0.90 <X<
1.11
500 Hz
30,000
13.44
0.90 <X<
1.11
1,000 Hz
60,000
13.44
0.85 <X<
1.18
5,000 Hz
300,000
13.44
0.85 <X<
1.18
10,000 Hz
600,000
13.44
0.85 <X<
1.18
