Chapter 2 – System Overview
Honeywell Confidential: Use or disclosure of information on this page is subject to the restrictions on the title page.
13841 Rev A
16
Characteristic
Specifications (continued)
Input sensitivity
19 mV/IPS peak
Signal Conversion (Magnetic Pickup Inputs)
Input frequency range
100 to 50,000 RPM
RPM accuracy
0.15%
Input voltage range
0.5V to 12.0V peak nominal, diode
protected
Coupling
Type - dc
Interface Specifications
Vibration transducer
2-each, Model 7310 Velocimeter
(19 mV/IPS sensitivity)
Magnetic pickup/
tachometer
2-each, pulse input, magnetic pickup or
logic type
PC or printer
1 serial, RS-232, 9600 baud
Accessory power
4-each, D-cell batteries, reverse-polarity,
circuit-protected and fused
Physical Particulars
Dimensions (including
mounting flanges)
Nominal measurements (in inches) are
• Height - 7.38
• Width - 7.25
• Depth - 1.81
Weight
3.5 lb nominal
