Chapter 2 – System Overview
Honeywell Confidential: Use or disclosure of information on this page is subject to the restrictions on the title page.
13841 Rev A
22
Characteristic
Specifications (Continued)
Phase accuracy
±15°
Balance frequency range
120 to 30,000 RPM
Spectrum Analysis
Analysis ranges
(maximum frequencies)
1200, 3000, 6000, 12,000, 30,000, 60,000,
120,000, 300,000 and 600,000 RPM
Window type
Flat top
FFT resolution
400 lines
Signal Conversion (Vibration Inputs)
Channel configuration
options
Sensor type - Model 7310 Velocimeter
Coupling
Type - ac
High-pass filter
3-pole Chebyshev, -3.0 dB @ 1.5 Hz
Analog-to-digital
converter type
13-bit
Spurious free dynamic
range
> 50 dB
Input ranges
0 to 380 mV peak (20 IPS)
Input sensitivity
19 mV/IPS peak
Signal Conversion (Magnetic Pickup Inputs)
Input frequency range
100 to 50,000 RPM
RPM accuracy
0.15%
