HP 4155A Programmer's Guide

Sample Application Programs
Flash EEPROM Test
Stress setup le for write pulse of NOR type.
Stress setup for write pulse of NOR type is stored in \NORWRT.STR" le on
provided diskette. As described previously, if you use your own setup le
with a dierent le name, change line 2010.
In the NORWRT.STR le, the following is set up.You can modify these
settings in the NORWRT.STR le or your own le:
 PGUs
Unit Period Width Delay
Time
Peak
Value
Base
Value
Leading
Time
Trailing
Time
Impedance
PGU1 (Gate) 1.03 ms 1.02 ms 0.0 s 14 V 0V 1  s 1  s 50 ohm
PGU2 (Drain) 1.00 ms 10  s 7V 0V 1  s 1  s 50 ohm
 Constant source setup
Unit Source Compliance
SMU2 (Source) 0V 100 mA
SMU4 (Substrate) 0V 100 mA
Stress setup le for erase pulse of NOR type.
Stress setup for erase pulse is stored on \NORERS
.STR" le on provided
diskette. As described previously, if you use your own setup le with a
dierent le name, change line 2020.
In the NORERS.STR le, the following is set up.You can modify these settings
in the NORERS.STR le or your own le:
 Constant source setup
Unit Source Compliance
SMU2 (Source)
1
11 V 100 mA
SMU4 (Substrate) 0V 100 mA
1 Erase pulse source
 Erase pulse width
Pulse width of erase pulse is specied as stress DURATION and set to 20ms.
6-12
