Model 5340A
Installation and Remote Programming
J
in
its
remote programming storage cells the initial conditions
of
0,
P,
@,
J,
L, and
N.
There are:
0
-
1
Hz resolution
P
-
10 Hz to
18
GHz range
@
-
AUTO (sweeps through all ranges)
J
-
Internal Sample Rate
L
-
Output ONLY IF addressed
N
-
Local operation
When taking remote control of the
5340A
it
is
necessary to change only those cells that
are different from the above. For example, if the
5340A is to be used under remote con
-
trol,
1
Hz resolution, 10 Hz
to
18
GHz range, automatic searching, sample rate HOLD
and WAIT in output phase until addressed;
it
is
only necessary to change the ASCII
“J”
to
.
These changes can be made in any order.
“KP9, “L97
to
“M”, and ‘“79
to
“0”
2
-
47.
What
is
Outputted
2
-
48. When addressed to TALK the 5340A outputs
a
string of 16 ASCII characters provided there
is
an addressed LISTENER on the bus. The handshake routine, necessary for passing infor
-
mation on the data lines, cannot be started unless there
is
both an addressed LISTENER and
TALKER on the bus.
The LISTENER must be able to recognize LF (line feed)
as
the end of the
5340A’s output data. As soon
as
the LISTENER accepts LF (sets DAC high) the 5340A leaves the
output phase and continues through its operating cycle.
2
-
49. The 16 output characters, their description and the order in which they are outputted are
shown in Table 2
-
5. Refer to Table
2
-
2
for signal levels.
Table 2
-
5. 5340A Output Code Set
ORDER
OUTPUTTED
1
2
3
4
thru
11
12
13
14
15
16
CHARACTER
D/L
O/SP
SP
0
-
9
E
-+
0
-
6
CR
LF
DESCRIPTION
D
-
measurement made direct
L
-
measurement made using phase locked loops
or
0
-
5340A’s display has overflowed
SP
-
Space
(0
100
000
binary, 040 octal)
or
Space
Digits
0
thru
9
(blank display digits outputted
as
0)
most significant digit first
Power of
10
exponent to follow
Exponent
is
positive
(
0
101 011 binary, 053 octal)
One digit exponent
Carriage return
(0
001 101 binary, 015 octal)
Line feed (used as
a
word terminator)
(0
001 010 binary,
012 octal)
2
-
50.
Modes
of
Operation
‘
2
-
51. The 5340A has sevLrk1 remote operating modes. They depend on the Sample Rate and
Output modes and the
,mdhod used to initiate a measurement procedure. This section includes
a description of these modes,
a
simplified flow chart (Figure 2
-
5) showing all operating modes
and
a
sample program.
i
i
2
-
15
