Model 5340A
Manual Changes and Options
.". 3
SECTION VII
MANUAL CHANGES AND OPTIONS
7 - 1. INTRODUCTION
7 - 2. This section contains information necessary to adapt this manual to older instruments. Also
included is information for available options. Options are covered starting with paragraph 7 - 9.
Field installation of options are covered in paragraph 7 - 19. Refer to Section I1 for ASCII remote
programming information.
7 - 3. MANUAL CHANGES
7
- 4. This manual applies directly to Model 5340A with serial prefix 1532A. See paragraph 1 - 4
for serail number identification.
7 - 5. Newer Instruments
7
- 6. As changes are made, newer instruments may have serial prefixes that are not listed in this
manual.
The manual for these instruments are supplied with
a manual change sheet which con -
tains the required updating information. If this sheet is missing, contact the nearest Hewlett-
Packard Sales and Service Office listed at the back of this manual.
7 - 7. Older Instruments
7
- 8. To adapt this manual to instruments having serial prefixes below 1532A, refer to Table 7 - 1
for backdating that applies to your instrument serial prefix.
Table 7
- 1. Manual Backdating
-~ ~~ ~
If Your Instrument Has
Serial Prefix
1440A
1416A
1408A
1348A
1344A
1328A
1324A
1320A
1312A
1252A
1248A
1244A
1236A
Make the Following Changes
to Your Manual
1
172
1,273
132,394
1,293,495
1,2,3,4,5,6
1,2,3,4,5,6,7
1,2,3,4,5,6,7,8
1,2,3,4,5,6,7,8,9
1,2,3,4,5,6,7,8,9,10
1,2,3,4,5,6,7,8,9,10,11
1,2,3,4,5,6,7,8,9,10,11,12
1,2,3,4,5,6,7,8,9,10,11,12,13
CHANGE 1
Table 6 - 1, A2A4 Replaceable Parts:
Change
series number for 05340 - 60040 (A2A4) from 1532 to 1344A.
Change A2A4C20 and A2A4C22 to 0160 - 0363 C:FXD MICA 620PF 5%, 28480,0160 - 0363.
Change
A2A4C21 to 0160 - 2202 C:FXD MICA 75PF 5%, 28480,0160 - 2202.
Change
A2A4L8 and A2A4L10 to 9100 - 2244 CO1L:FXD RF O.1UH lo%, 28480,9100 - 2247
Change
A2A4L9 to 9140 - 0158 1UH lo%, 99800, 1025 - 20.
'1
Delete C8 and descriptipn.
Table 6 - 1, A2 Parts List:
Table 6 - 1, A4 Replaceabie @arts:
Change series num ei'for 05340 - 60002 (A4) to 1220A.
Change A4R22 to 6" 757 - 0932 R:FXD MET FLM 2.2K OHM 2% 1/8W, 28480, 0757 - 0932 (Note
that some A4 boards with series
1220A may have 1800 ohm resistors installed).
7
- 1
